NF FRA5022 FREQUENCY RESPONSE ANALYZER 0.1MHZ-100KHZ FRA5022 is a compact, 2-channel frequency response analyzer (FRA) designed for measurements in servo systems, switching power supplies, and electrochemical impedance analysis. Key Specifications • Frequency Range: 0.1 mHz to 100 kHz • Gain / Amplitude Accuracy: ±0.05 dB • Phase Accuracy: ±0.3° • Dynamic Range: 120 dB (supported by auto-ranging and a high-resolution A/D converter) • Isolation: Oscillator output and 2-channel analysis inputs are isolated from the cabinet by 250 Vrms • Display: 3.5-inch color TFT-LCD for viewing graphs (like Bode plots) and measurement values • Form Factor: Slim, space-efficient 2U rack-mount design (88 mm height)
